Aims to be a premier solution provider for high quality, efficient, safe, environmental power
1 Years
| Ask Lasest Price | |
| Certification : | CE, RoHS, MSDS, Un38.3 |
| Brand Name : | RESKY |
| Model Number : | LP9034102SH30 |
| Price : | Negotiable |
| Payment Terms : | Western Union,T/T |
| Supply Ability : | 5000pcs/day |
| Delivery Time : | 7-10workdays |
RC Lipo Battery Pack 30c 14.8V 2600mAh 4s RC Lithium-Ion Polymer Batteries
| NO. | Items | Specifications |
| 1 | batteries | 14.8V 2600mah lipo battery |
| 2 | Charge voltage | 16.8V |
| 3 | Nominal voltage | 11V |
| 4 | Nominal capacity | 2600mAh 30C Discharge |
| 5 | Charge current | Standard Charging:0.2C Rapid charge: 30C |
| 6 | Standard Charging method | 0.5C CC(constant current)charge to 16.8V, then CV(constant voltage 16.8V)charge till charge current decline to ≤0.05C |
| 7 | Charging time | Standard Charging:2.75hours(Ref.) Rapid charge: 2hours(Ref.) |
| 8 | Max.charge current | 0.5C |
| 9 | Max.discharge current | 30.0C |
| 10 | Discharge cut-off voltage | 8.25V(0.2C) |
| 11 | Operating temperature | Charging: 0 °C ~45 °C Discharging:0 °C ~45 °C |
| 12 | Storage temperature | -10°C~ +45 °C |
| 13 | Dimension | Length:102±0.5mm (not including tabs) Width:34±0.5mm Thickness:29±0.2mm |
| 14 | Drop Test | The cell is to be dropped from a height of meter twice onto concrete ground. No fire, no leakage |
| 15 | cycle time | ≥800times |
Why we choose lithium polymer battery pack for rc products?
RC products often require high power output for short periods, such as during acceleration or high-speed maneuvers. Lithium polymer batteries can support high discharge rates, providing the burst of power needed for these applications.
Lithium polymer batteries use a solid or gel-like electrolyte, which is less likely to leak or cause a fire if damaged. This improved safety is an important consideration for RC products, which may be operated in various environments and conditions.
Lithium polymer batteries are lighter than many other types of batteries, which can help reduce the overall weight of RC products. This can improve performance and maneuverability, especially in aircraft and vehicles.
Lithium polymer batteries have a low self-discharge rate, meaning they retain their charge for longer periods when not in use. This can be beneficial for RC products that are not used frequently or that require long periods of storage.
Picures:
|
|
