Aims to be a premier solution provider for high quality, efficient, safe, environmental power
2 Years
| Ask Lasest Price | |
| Certification : | CE, RoHS, MSDS, Un38.3 |
| Brand Name : | RESKY |
| Model Number : | LP605080 |
| Price : | Negotiable |
| Payment Terms : | T/T,Western Union |
| Supply Ability : | 100000PCS/Day |
| Delivery Time : | 7-10days |
| NO. | Items | Specifications |
| 1 | batteries | 3.7v 3000mah lipo battery |
| 2 | Charge voltage | 4.2V |
| 3 | Nominal voltage | 3.7V |
| 4 | Nominal capacity | 3000mAh 0.2C Discharge |
| 5 | Charge current | Standard Charging:0.5C Rapid charge: 1.0C |
| 6 | Standard Charging method | 0.5C CC(constant current)charge to 4.2V, then CV(constant voltage 4.2V)charge till charge current decline to ≤0.05C |
| 7 | Charging time | Standard Charging:2.75hours(Ref.) Rapid charge: 2hours(Ref.) |
| 8 | Max.charge current | 1.0C |
| 9 | Max.discharge current | 1.0C |
| 10 | Discharge cut-off voltage | 2.5V0.25V(0.2C) |
| 11 | Operating temperature | Charging: 0 °C ~45 °C Discharging:0 °C ~45 °C |
| 12 | Storage temperature | -10°C~ +45 °C |
| 13 | Dimension | Length:80±2mm (not including tabs) Width:50±0.5mm Thickness:6±0.2mm |
| 14 | Drop Test | The cell is to be dropped from a height of meter twice onto concrete ground. No fire, no leakage |
| 15 | cycle time | ≥500times |
Advantages:
Safety:
Lower Thermal Runaway Risk: The polymer electrolyte used in these batteries has better thermal stability compared to liquid electrolytes in some other battery chemistries. This reduces the risk of thermal runaway, which could lead to dangerous situations such as fire or explosion. For example, in electric vehicles, the use of flat lithium polymer batteries with good thermal stability can enhance the overall safety of the vehicle.
No Liquid Leakage: Since there is no liquid electrolyte, there is no risk of leakage, which can damage the device or cause safety hazards. This makes them more reliable and suitable for a wide range of applications, including those where the device may be in different orientations or subjected to vibrations.
Low Self-Discharge Rate: They have a relatively low self-discharge rate, meaning they can retain their charge for longer periods when not in use. This is beneficial for devices that are not used frequently or for backup power applications. For example, a flat lithium polymer battery-powered emergency light that is stored for long periods will still have a significant amount of charge when needed.
Good Charge and Discharge Efficiency: They can be charged and discharged relatively efficiently, with charge/discharge efficiencies typically ranging from 80% to 90%. This means that less energy is wasted during the charging and discharging process, resulting in better overall energy utilization.
Pictures:
|
|
